SPECIFICATION | Operating Conditions | |
RATED CAPACITY | 280Ah | 25℃@0.5P/0.5P |
RATED VOLTAGE | 3.2V | |
OPERATING VOLT | 2.5V~3.65V / 2.0V-3.65V | T>0℃ / T≤0℃ |
CELL IMPEDANCE | 0.18±0.05mΩ | @1kHz,40% SOC |
ENERGY DENSIT | ≥165Wh/kg | 25℃@0.5P/0.5P |
WEIGHT | 5.43±0.20kg | |
CYCLE LIFE | ≥10000次 | 25℃@100%DOD,70%EOL,0.5P/0.5P |
DIMENSION | 71*173*207 | T(mm)*W(mm)*H(mm) |
