| SPEC | AIR COOLED MODULE | LIQUID COOLED MODULE |
| CELL TYPE | 71173207-280Ah，LFP | 71173207-280Ah，LFP |
| RATED VOLTAGE | 51.2V | 153.6V |
| RATED CAPACITY | 14.336kWh | 43.008kWh |
| CONFIGURATION | 1P16S | 1P48S |
| C RATE | 0.5P/0.5P | 0.5P/0.5P |
| VOLTAGE RANGE | 40.0V-58.4V | 120V-175.2V |
| TEMPERATURE | Charing：0℃~55℃ Discharging：-20℃~55℃ | Charing：0℃~55℃ Discharging：-20℃~55℃ |
| ALTITUDE | ≤4000m | ≤4000m |
| DIMENSION | L745*W420*H226mm | L1096*W814*H242mm |
| WEIGHT | 105±3Kg | 318±5Kg |
| THERMAL MGMT | Intelligent Air Cooling | Intelligent Liquid Cooling |
| DELTA T | ≤3℃ | ≤3℃ |
| STORAGE TEMP | -20℃~45℃ | -20℃~45℃ |
| STORAGE HUMIDITY | 5%-95% | 5%-95% |
| STANDARD | GB/T36276-2018 | GB/T36276-2018 |
